trip leads to misinterpretations of
the oil fill quantity.
To ensure that the display of the
engine oil level is correct, only
check the oil level with the en-
gine at operating temperature.
Switch off engine at operating
temperature.
Fold out side stand and posi-
tion yourself on right-hand side
of motorcycle.
Hold motorcycle straight.
with center stand
OE
Place motorcycle on center
stand, ensuring that it is rest-
ing on a firm and level support
surface.
Wait five minutes to allow oil to
drain to the oil pan.
Read oil level in display 1.
Specified level of engine
oil
between MIN- and MAX mark
If the oil level is below MIN mark:
Topping up engine oil ( 113).
If the oil level is above MAX
mark:
Have oil level corrected at
an authorized service facility,
preferably an authorized
BMW Motorrad retailer.
Topping up engine oil
Park the motorcycle, ensuring
that the support surface is firm
and level.
Wipe area around oil fill loca-
tion to clean it.
8
113
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
