BMW R 1200R 2015 User Manual

Limit range for outside
temperature
Approx. 37 °F (Approx. 3 °C)
In addition, the ice crystal
symbol 2 is displayed.
The outside temperature
warning does not mean that
there is no risk of icy conditions
at measured temperatures above
37 °F (3 °C).
At a low outside temperature,
icy conditions must especially
be expected on bridges and in
shady road areas.
Tire inflation pressure
with Tire Pressure Control
(TPC)
OE
The tire pressures are
shown adjusted for tem-
perature on the multifunction
display and are always relative
to the following tire air temper-
ature:
68 °F (20 °C)
The figure on the left side 2 in-
dicates the front tire's inflation
pressure, while the figure on the
right 3 shows the inflation pres-
sure in the rear tire. Immediately
after switching on the ignition,
"-- --" is indicated.
TPC sensor is not active
min 19 mph (min 30 km/h)
(The TPC sensor does not
transmit a signal to the motor-
cycle until this minimum speed
has been exceeded.)
If the 1 symbol appears at
the same time, the display
is a warning. The critical tire-
inflation pressure flashes.
If the level concerned is
borderline in terms of the
permissible tolerance, the gen-
eral warning light also shows yel-
low. If the monitored tire inflation
pressure is outside the specified
range the general warning light
will flash in red.
3
42
z Displays

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
