BMW R 1200R 2015 User Manual

Tighten rear wheel on
wheel flange
Tightening sequence: tighten
diagonally
44 lb/ft (60 Nm)
Mounting muffler ( 128).
Muffler
Swivel muffler
Risk of skin burns from hot
exhaust system.
Do not touch hot parts of the
exhaust system.
Let rear muffler cool down.
Make sure ground is level and
firm and place motorcycle
on a suitable auxiliary stand.
BMW Motorrad recommends
the BMW Motorrad rear-wheel
stand.
Mounting rear-wheel stands
( 112).
with center stand
OE
Make sure ground is level and
firm and place motorcycle on
its center stand.
Remove screws 1.
Pull cover 2 out of holder 3
and remove.
Unscrew nut 1 to loosen
clamp 2 somewhat.
Remove screw 1 and
washer 2.
Turn muffler 3 counterclock-
wise.
8
127
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
