A Engine is switched off
B Operating position
Lights
Low-beam headlight and
parking lights
The parking lights come on au-
tomatically when the ignition is
switched on.
The parking lights are a
strain on the battery. Do
not leave the ignition switched
on longer than absolutely
necessary.
The low-beam headlight switches
on automatically when the engine
is started.
High-beam headlight and
headlight flasher
Switching on ignition ( 46).
Press switch 1 toward front to
switch on high-beam headlight.
Pull switch 1 toward rear to
actuate headlight flasher.
Parking lights
Switch off ignition ( 47).
Immediately after switching off
ignition, push button 1 to left
and hold it until parking lights
come on.
Switch ignition on and then off
again to switch off parking light.
Additional LED headlight
with additional LED
headlight
OA
Requirement: the LED addi-
tional headlights are only active
if the low-beam headlight is ac-
tive; if the daytime driving light is
switched on, the LED additional
4
53
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
