BMW R 1200R 2015 User Manual

Raise the rear of the topcase
and pull it off luggage rack.
Mounting topcase
Topcase not fastened cor-
rectly can reduce riding
safety.
Topcase must not shake and
must be fastened clearance-
free.
Fold up handle as far as possi-
ble.
Hook topcase into luggage
rack. Make sure that hooks 1
engage securely in their
mounts 2.
Press handle 1 down until it
engages.
Turn key in Topcase lock into
Position 1 and remove.
Navigation system
Fasten navigation system
securely
with preparation for navigation
system
OE
with navigation system
OA
The navigation preparation
is suitable for the
BMW Motorrad Navigator IV and
the BMW Motorrad Navigator V.
The locking system of the
Mount Cradle offers no pro-
tection against theft.
Remove the navigation system
and store in a safe place after
every drive.
9
151
z Accessories

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
