BMW R 1200R 2015 User Manual

remains off or continues to
flash.
ABS is switched on.
As an alternative, the ignition
can also be switched off and
then on again.
ABS error
If the ABS warning light lights
up after switching the ignition
off and on and then contin-
uing driving above the mini-
mum speed, an ABS fault has
occurred. (Minimum speed
3 mph (5 km/h))
Automatic Stability
Control
Deactivating ASC/DTC
You can find more detailed
information regarding ASC
and DTC in the "Technology in
detail" chapter.
Switching on ignition ( 46).
Press and hold button 1 un-
til ASC/DTC warning light's
display changes.
The ASC/DTC function can
also be deactivated while
riding.
lights up.
Release button 1 within two
seconds.
continues to light up.
ASC/DTC is now deactivated.
Activating ASC/DTC
Press and hold button 1 un-
til ASC/DTC warning light's
display changes.
The ASC/DTC function can
also be switched on while
riding.
goes out. If self-diagnosis
has not been completed,
the warning light begins to flash.
4
65
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
