BMW R 1200R 2015 User Manual

Rear-wheel drive
Type of final drive Shaft drive with bevel gears
Type of rear suspension Cast-aluminum single swing arm with
BMW Motorrad paralever
Gear ratio of final drive 2.818 (31/11 teeth)
Suspension
Front wheel
Type of front suspension Upside-down telescopic forks
Spring travel, front 5.5 in (140 mm), on front wheel
Rear wheel
Type of rear suspension Cast-aluminum single swing arm with
BMW Motorrad paralever
Type of rear suspension Central spring strut with coil spring, adjustable
rebound-stage damping and spring preload
with Dynamic ESA
OE
Central spring strut with coil spring, electrically
adjustable damping and spring preload
Spring travel at rear wheel 5.5 in (140 mm)
11
169
z Technical data

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
