BMW R 1200R 2015 User Manual

Fasten negative battery ca-
ble 1.
Fasten battery with rubber
strap 2.
Insert battery cover into
mount 1 and press it into
mounts 2.
Install screw 1.
Setting clock ( 59).
Set date ( 59).
Fuses
Replace fuses
Switch off ignition.
Remove rider's seat ( 79).
Disconnect plug 1.
If defective fuses are
bridged, this results in a
danger of short-circuit and thus a
danger of fire.
Replace defective fuses with new
fuses.
Consult the fuse assignment
diagram and replace the defec-
tive fuse.
8
143
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
