BMW R 1200R 2015 User Manual

Warning and indicator
lamps
Warning symbols in the
display panel
Meaning
appears on the
display
Low engine oil level ( 32)
flashes red
appears on the
display
Tire inflation pressure is outside ap-
proved range (
33)
lights up yellow appears on the
display
Sensor defective or system error
( 33)
"--" or "-- --"
is indicated.
"--" or "-- --"
is indicated.
Transmission error ( 34)
lights up yellow appears on the
display
Battery of tire-inflation pressure sensor
weak ( 34)
lights up yellow appears on the
display
Light failure ( 35)
lights up yellow appears on the
display
Front light failure (
35)
lights up yellow appears on the
display
Rear light failure ( 35)
3
27
z Displays

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
