BMW R 1200R 2015 User Manual

Press button 1 briefly to re-
spectively switch to next menu
item.
It is possible to choose
between the following menu
items in the top line of the
display 2:
ENGINE
DTC
Repeat pressing button 4
briefly, until the desired value
is shown in bottom line of
display 3.
Briefly press button 1 repeat-
edly until User EXIT is dis-
played.
Press and hold button 4 to exit
User menu.
Cruise-control system
with cruise control
OE
Switch on cruise-control
system
Push switch 1 to right.
Button 2 is unlocked.
Store speed
Briefly press button 1 forward.
Adjustment range of
cruise-control system
12...130 mph (20...210 km/h)
Cruise-control system indi-
cator light lights up.
The motorcycle maintains your
current cruising speed and the
setting is saved.
4
70
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
