BMW R 1200R 2015 User Manual

Press button 1 to left to switch
on left-side turn indicators.
Press button 1 to right to
switch on right-side turn
indicators.
Press button 1 into center po-
sition to switch off turn indica-
tor.
The turn indicators
automatically switch
off when the defined driving
time and distance have been
reached. The defined riding
time and distance can be set by
an authorized BMW Motorrad
retailer.
Multifunction display
Support for menu
guidance
Arrows in the display have the
following meaning:
Arrows 1 and 3: Press and
hold the respective button.
Arrow 2: Briefly press the re-
spective button.
Setting individual display
view
Switching on ignition ( 46).
Repeatedly press button 1
briefly, until STYLE is shown
in bottom line of display 2.
Press and hold button 1 to
change Display view. The
numbers have the following
meaning information:
0: Full view
1: Sport view
2: Touring view
The selected Display view is
shown in the area 2.
Selecting view on onboard
computer
Switching on ignition ( 46).
4
55
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
