BMW R 1200R 2015 User Manual

Pull quick-release axle 1 out
while supporting the front
wheel.
Place front wheel down and
roll it forward out of the front
suspension.
Remove spacer bushing 1 from
the wheel hub.
Installing front wheel
Malfunctions may occur
during control interventions
by ABS or ASC/DTC if a wheel
other than the standard wheel is
installed.
Please see the information on
the effect of wheel sizes on the
ABS and ASC/DTC chassis con-
trol systems at the beginning of
this chapter.
Threaded fasteners not
tightened to the specified
torque can work loose or their
threads can suffer damage.
Always have the tightening
torques checked by a specialized
workshop, preferably an
authorized BMW Motorrad
retailer.
Mount spacing bushing 1 on
left side in wheel hub.
The front wheel must be
installed right way round to
rotate in the correct direction.
Observe the direction of rota-
8
123
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
