BMW R 1200R 2015 User Manual

Rear-wheel stand
Mounting rear-wheel
stands
Park motorcycle, ensuring that
support surface is firm and
level.
Use basic stand with rear
wheel adapter. The basic
stand and its accessories
are available through your
authorized BMW Motorrad
retailer.
Set desired height of rear-
wheel stand using bolts 1.
Remove the lock washer 2; to
do so, press the unlock but-
ton 3.
Push the rear-wheel stand from
the right onto the rear axle.
Apply the retaining disk from
the left; to do so, press the un-
lock button.
Position motorcycle upright
while simultaneously pressing
grip of stand back so that both
stand rollers rest on ground.
Then press the grip down to
the ground.
Engine oil
Check engine oil level
The oil level varies with
the temperature of the
oil. The higher the temperature,
the higher the level of oil in the
sump. Checking the oil level with
the engine cold or after a short
8
112
z Maintenance

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
