Release button 1 within two
seconds.
remains off or continues to
flash.
ASC/DTC is now activated.
As an alternative, the ignition
can also be switched off and
then on again.
ASC/DTC error
If the ASC/DTC warning light
lights up after switching the
ignition off and on and then
continuing driving above the
minimum speed, an ASC/
DTC fault has occurred. (Min-
imum speed min 3 mph (min
5 km/h))
Electronic suspension
adjustment
with Dynamic ESA
OE
Adjustment options
Using the Dynamic ESA elec-
tronic suspension adjustment
system you can easily adjust your
motorcycle to the load being car-
ried.
Using leveling sensor, Dy-
namic ESA detects movements
of the running gear and responds
to them by adjusting the damper
valves. As a result, the running
gear is adjusted to the conditions
of the ground.
Starting from the basic setting
(ROAD), the damping can also be
set harder (DYNAMIC).
Setting suspension
compliance
Switching on ignition ( 46).
Spring preload is displayed in
the multifunction display in area
1, and damping is indicated in
area 2.
4
66
z Operation

BMW R 1200R 2015 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	92 kW (125 hp) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Transmission	6-speed
Final Drive	Shaft drive
Rear Brakes	Single disc brake, diameter 276 mm, double-piston floating caliper
ABS	BMW Motorrad ABS
Fuel Capacity	18 liters
Length	2, 145 mm
Wheelbase	1, 495 mm
Engine Type	Air/liquid-cooled four stroke flat twin engine, double overhead camshaft, one balance shaft
Frame	Two-section frame
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminium single-sided swing arm with BMW Motorrad Paralever
Front Brakes	Twin disc brake, floating brake discs, diameter 320 mm, four-piston radial calipers
Seat Height	790 mm
Weight	231 kg
Top Speed	200 km/h
