7-14
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 7 Configuring LAN Ports for Layer 2 Switching
Configuring LAN Interfaces for Layer 2 Switching
Router# show interfaces fastethernet 5/8 switchport
Name: Fa5/8
Switchport: Enabled
Administrative Mode: dynamic desirable
Operational Mode: trunk
Administrative Trunking Encapsulation: negotiate
Operational Trunking Encapsulation: dot1q
Negotiation of Trunking: Enabled
Access Mode VLAN: 1 (default)
Trunking Native Mode VLAN: 1 (default)
Trunking VLANs Enabled: ALL
Pruning VLANs Enabled: ALL
Router# show interfaces fastethernet 5/8 trunk
Port Mode Encapsulation Status Native vlan
Fa5/8 desirable n-802.1q trunking 1
Port Vlans allowed on trunk
Fa5/8 1-1005
Port Vlans allowed and active in management domain
Fa5/8 1-6,10,20,50,100,152,200,300,303-305,349-351,400,500,521,524,570,801-8
02,850,917,999,1002-1005
Port Vlans in spanning tree forwarding state and not pruned
Fa5/8 1-6,10,20,50,100,152,200,300,303-305,349-351,400,500,521,524,570,801-8
02,850,917,999,1002-1005
Router#
Configuring a LAN Interface as a Layer 2 Access Port
Note If you assign a LAN port to a VLAN that does not exist, the port is shut down until you create the VLAN
in the VLAN database (see the “Creating or Modifying an Ethernet VLAN” section on page 9-10).
To configure a LAN port as a Layer 2 access port, perform this task:
Command Purpose
Step 1
Router(config)# interface type
1
slot/port
Selects the LAN port to configure.
Step 2
Router(config-if)# shutdown
(Optional) Shuts down the interface to prevent traffic flow
until configuration is complete.
Step 3
Router(config-if)# switchport
Configures the LAN port for Layer 2 switching.
Note You must enter the switchport command once
without any keywords to configure the LAN port
as a Layer 2 port before you can enter additional
switchport commands with keywords.
Step 4
Router(config-if)# no switchport
Clears Layer 2 LAN port configuration.
Step 5
Router(config-if)# switchport mode access
Configures the LAN port as a Layer 2 access port.
Router(config-if)# no switchport mode
Reverts to the default switchport mode (switchport mode
dynamic desirable).
