32-51
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 32 Configuring PFC QoS
Configuring PFC QoS
By default, microflow policers affect only routed traffic. To enable microflow policing of bridged traffic
on specified VLANs, perform this task:
This example shows how to enable microflow policing of bridged traffic on VLANs 3 through 5:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# interface range vlan 3 - 5
Router(config-if)# mls qos bridged
Router(config-if)# end
Router#
This example shows how to verify the configuration:
Router# show mls qos | begin Bridged QoS
Bridged QoS is enabled on the following interfaces:
Vl3 Vl4 Vl5
<...output truncated...>
Router#
Enabling or Disabling PFC Features on an Interface
You can enable or disable the PFC QoS features implemented on the PFC for traffic from an interface
(see the PFC Marking and Policing section on page 32-16). Disabling the PFC QoS features on an
interface leaves the configuration intact. The mls qos interface command reenables any previously
configured PFC QoS features. The mls qos interface command does not affect the port queueing
configuration.
To enable or disable PFC features for traffic from an interface, perform this task:
Command Purpose
Step 1
Router(config)# interface {{vlan vlan_ID} |
{type
1
slot/port}}
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet
Selects the interface to configure.
Step 2
Router(config-if)# mls qos bridged
Enables microflow policing of bridged traffic, including
bridge groups, on the VLAN.
Router(config-if)# no mls qos bridged
Disables microflow policing of bridged traffic.
Step 3
Router(config-if)# end
Exits configuration mode.
Step 4
Router# show mls qos
Verifies the configuration.
Command Purpose
Step 1
Router(config)# interface {{type
1
slot/port} |
{port-channel number}}
1. type = ethernet, fastethernet, gigabitethernet, tengigabitethernet, ge-wan, pos, or atm
Selects the interface to configure.
Step 2
Router(config-if)# mls qos
Enables PFC QoS on the interface.
Router(config-if)# no mls qos
Disables PFC QoS on the interface.
Step 3
Router(config-if)# end
Exits configuration interface.
Step 4
Router# show mls qos
Verifies the configuration.
