Cisco 7609 User Manual

35-10
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 35 Configuring Web Cache Services Using WCCP
Configuring WCCP
For network configurations where redirected traffic needs to traverse an intervening router, the router
being traversed must be configured to perform IP multicast routing. You must configure the following
two components to enable traversal over an intervening router:
• Enable IP multicast routing using the ip multicast routing interface configuration command.
• Enable the interfaces to which the cache engines will connect to receive multicast transmissions
using the ip wccp group-listen interface configuration command (note that earlier Cisco IOS
versions required the use of the ip pim interface configuration command).
Using Access Lists for a WCCP Service Group
To configure the router to use an access list to determine which traffic should be directed to which cache
engines, perform this task in global configuration mode:
To disable caching for certain clients, perform this task in global configuration mode:
Setting a Password for a Router and Cache Engines
MD5 password security requires that each router and cache engine that wants to join a service group be
configured with the service group password. The password can consist of up to seven characters. Each
cache engine or router in the service group will authenticate the security component in a received WCCP
packet immediately after validating the WCCP message header. Packets failing authentication will be
discarded.
Step 2
Router(config)# interface type number
Specifies the interface to be configured for multicast
reception.
Step 3
Router(config-if)# ip wccp {web-cache |
service-number} group-listen
Enables the reception of IP multicast packets (content
originating from the cache engines) on the interface
specified in Step 2.
Command Purpose
Command Purpose
Step 1
Router(config)# access-list access-list permit ip
host host-address [destination-address |
destination-host | any]
Creates an access list that enables or disables traffic
redirection to the cache engine.
Step 2
Router(config)# ip wccp web-cache group-list
access-list
Indicates to the router from which IP addresses of cache
engines to accept packets.
Command Purpose
Step 1
Router(config)# access-list access-list permit ip
host host-address [destination-address |
destination-host | any]
Creates an access list that enables or disables traffic
redirection to the cache engine.
Step 2
Router(config)# ip wccp web-cache redirect-list
access-list
Sets the access list used to enable redirection.

Cisco 7609 Specifications

General

Chassis Slots	9
Switch Fabric Capacity	720 Gbps
Power Supply Options	AC or DC
Product Type	Router
Form Factor	Rack-mountable
Supported Line Cards	Various Cisco 7600 Series line cards
Operating System	Cisco IOS
Management	CLI, SNMP
Forwarding Performance	400 Mpps
Maximum Power Consumption	4000 Watts
Redundancy	Yes
Interfaces/Ports	Various, depending on line cards installed
