19-10
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 19 Configuring IP Unicast Layer 3 Switching on Supervisor Engine 1
Displaying IP MLS Cache Entries
This example shows how to display IP MLS information:
Router# show mls ip
DstIP SrcIP DstVlan-DstMAC Pkts Bytes
-----------------------------------------------------------------------
SrcDstPorts SrcDstEncap Age LastSeen
--------------------------------------
172.20.52.122 0.0.0.0 5 : 00e0.4fac.b3ff 155 6290
5 /9 ,5 /9 ARPA,ARPA 661 15:09:32
Number of Entries Found = 1
Router#
Displaying IP MLS Cache Entries for a Specific Destination Address
To display MLS entries for a specific destination IP address, perform this task:
This example shows how to display MLS entries for a specific destination IP address:
Router# show mls ip destination 127.1.1.1
DstIP/SrcIP Prot/SrcPt/DstPt DstMAC/DstVlan Pkts Bytes
----------- ---------------- -------------- ---- -----
127.1.1.1/127.1.1.1 udp/ 0040.0bd0.29fc/4095 92 111C
127.1.1.1/0.0.0.0 0040.0bd0.29fc/4095 0 0
Number of Entries Found = 2
Router#
Displaying Cache Entries for a Specific Source IP Address
To display MLS entries for a specific source IP address, perform this task:
Command Purpose
Router# show mls ip destination ip_address [any |
detail | flow [tcp | udp] | interface {{vlan vlan_ID}
| {type
1
slot/port} | {port-channel number}} | macd
destination_mac_address | macs source_mac_address |
multicast | source ip_address]
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet
Displays the IP MLS cache entries for a specific IP
destination address.
Command Purpose
Router# show mls ip source ip_address [any |
destination ip_address | detail | flow [tcp | udp] |
interface {{vlan vlan_ID} | {type
1
slot/port} |
{port-channel number}} | macd destination_mac_address
| macs source_mac_address | multicast]
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet
Displays the IP MLS source cache entries for a specific IP
source address.
