Cisco 7609 User Manual

12-6
Cisco 7600 Series Router Cisco IOS Software Configuration Guide—12.1E
78-14064-04
Chapter 12 Configuring Layer 3 Interfaces
Configuring AppleTalk Routing, Cable Ranges, and Zones
Configuring AppleTalk Routing, Cable Ranges, and Zones
For complete information and procedures, refer to these publications:
• Cisco IOS AppleTalk and Novell IPX Configuration Guide, Release 12.1, at this URL:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121cgcr/atipx_c/index.htm
• Cisco IOS AppleTalk and Novell IPX Command Reference, Release 12.1, at this URL:
http://www.cisco.com/univercd/cc/td/doc/product/software/ios121/121cgcr/atipx_r/index.htm
To configure routing for AppleTalk, perform this task beginning in global configuration mode:
This example shows how to enable AppleTalk routing and assign an AppleTalk cable-range and zone
name to interface VLAN 100:
Router# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Router(config)# appletalk routing
Router(config)# interface vlan 100
Router(config-if)# appletalk cable-range 100-100
Router(config-if)# appletalk zone Engineering
Router(config-if)# no shutdown
Router(config-if)# end
Router# copy running-config startup-config
Command Purpose
Step 1
Router(config)# appletalk routing
Enables AppleTalk routing.
Step 2
Router(config)# interface {vlan vlan_ID} |
{type
1
slot/port} | {port-channel
port_channel_number}
1. type = ethernet, fastethernet, gigabitethernet, tengigabitethernet, or ge-wan
Selects an interface to configure.
Step 3
Router(config-if)# appletalk cable-range
cable_range
Assigns a cable range to the interface.
Step 4
Router(config-if)# appletalk zone zone_name
Assigns a zone name to the interface.
Step 5
Router(config-if)# no shutdown
Enables the interface.
Step 6
Router(config-if)# end
Exits configuration mode.
Step 7
Router# show interfaces [{vlan vlan_ID} |
{type
1
slot/port} | {port-channel
port_channel_number}]
Router# show appletalk interfaces [{vlan vlan_ID}
| {type
1
slot/port} | {port-channel
port_channel_number}]
Router# show running-config interfaces [{vlan
vlan_ID} | {type
1
slot/port} | {port-channel
port_channel_number}]
Verifies the configuration.
