Configuring Device Security
Defining Access Control
ESW 500 Series Switches Administration Guide 168
5
STEP 4 Define the relevant fields,
STEP 5 Click Apply. The IP Based ACL is modified, and the device is updated.
Defining ACL Binding
When an ACL is bound to an interface, all the ACE rules that have been defined are
applied to the selected interface.
Whenever an ACL is assigned on a port or a
EtherChannel flows from that ingress interface that do not match the ACL are
matched to the default rule, which is Drop unmatched packets. To bind ACLs to an
interface:
STEP 1 Click Security > Access Control Lists (ACL) > ACL Binding. The ACL Binding Page
opens:
ACL Binding Page
The
ACL Binding Page contains the following fields:
• Copy From Entry Number — Copies the ACL binding configuration from the
specified table entry.
