Configuring Quality of Service
Managing QoS Statistics
ESW 500 Series Switches Administration Guide 298
12
STEP 2 Click the Add button. The
Add Queues Statistics
Page
opens.
Adding Queues Statistics
• The
Add Queues Statistics
Page contains the following fields:
• Select Counter Set — Selects the counter set.
• Interface — Defines the ports for which statistics are displayed. The possible
field values are:
- Port — Selects the port or which statistics are displayed.
- All Ports — Specifies that statistics are displayed for all ports.
• Queue — Selects the queue for which statistics are displayed.
• Drop Precedence — Selects the drop precedence assigned to the packets
forwarded or tail dropped for which statistics are displayed.
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The Queues Statistics are defined, and the device is updated.
Resetting Queue Statistics Counters
To clear the statistics counters, click the Clear Counters button.
