Configuring Quality of Service

Managing QoS Statistics

ESW 500 Series Switches Administration Guide 295

STEP 2 Click the Add button. The

Add Aggregate Policer

Page

opens.

The Add Aggregate Policer Page includes one field: the Aggregate Policer Name.

STEP 3 Define the relevant fields.

STEP 4 Click Apply. The Aggregate Police defined, and the device is updated.

Default Chapter3
