Configuring Quality of Service
Defining Advanced QoS Mode
ESW 500 Series Switches Administration Guide 325
12
Edit QoS Policy Profile Page
The
Edit QoS Policy Profile Page contains the following fields.
• Policy Name — Displays the user-defined policy name.
• Class Map — Displays the user-defined name of the class map.
• Action — Defines the action attached to the rule. The possible field value is:
• Trust CoS-DS CP — Determines the queue to which the packet is assigned
dependent on the CoS tag and DSCP tag.
• Set — Defines the Trust configuration manually. The possible field values
are:
- DSCP — In the New Value box, the possible values are 0-63.
- Queue — (applicable only to Gigabyte devices)
- CoS — In the New Value box, the possible values are 0-7. (applicable
only to Gigabyte devices)
• Police — Enables Policer functionality.
