Managing System Files
Active Image
ESW 500 Series Switches Administration Guide 369
14
STEP 1 Click Maintenance > File Management > Active Image. The
Active Image Page
opens:
Active Image Page
The
Active Image Page
contains the following fields:
• Active Image — Indicates the Image file which is currently active on the device.
• Version Number — Indicates the image version number currently active on the
device.
• After Reset — The Image file which is active after the device is reset. The
possible field values are:
-
Image 1
— Activates Image file 1 after the device is reset.
-
Image 2
— Activates Image file 2 after the device is reset.
• Version Number — Indicates the image version number that is active after the
device is reset.
STEP 2 Define the relevant fields.
STEP 3 Click Apply. The active image is defined, and the device is updated.
