Getting Started
Using The Switch Console Port
ESW 500 Series Switches Administration Guide 40
1
The current IP address setting for the ESW 500 series switch is shown. If the
switch is already connected to the network and obtained an IP address via DHCP,
this is the IP address which is used to launch the ESW 500 Switch Configuration
Utility.
If you need to change the IP address to a static IP address, perform the following
steps:
STEP 1 Use the Right arrow key to highlight Edit, then press Enter. The IPv4 Address field
should be highlighted.
STEP 2 Using the arrow keys to navigate around the window, and the enter key to apply
changes, modify the IPv4 Address, Subnet mask, and Default Gateway.
STEP 3 Change the DHCP Client field to be Disable by pressing the space bar.
STEP 4 Press the ESC key, press the right arrow to highlight Save, and press Enter to save
all changes.
