[SMB-66E]
－ 5 －
OPERATION
2
2.4 Edit Mode
The edit mode includes nine menu options.
Each function is described below.
1: EQL SEG ············· A new equal segment action program is automatically created through
interactive entry procedure.
2: NC ····················· A new program is created in the NC language.
3: READ·················· The program is loaded from the ABSODEX driver and edited.
4: CNT ···················· The program stored in the Teaching Pendant is edited continuously.
5: STORE ················ The edited program is saved in the ABSODEX driver.
6: LIST ··················· A list of program numbers stored in the ABSODEX driver is displayed.
7: NO. ···················· The program number is changed.
a) The number of the program being edited at the Teaching Pendant
is changed.
b) The number of the program stored in the ABSODEX driver is
changed.
8: DEL ···················· The designated program is deleted from the ABSODEX driver.
9: SAMPL ················ Nine sample programs (NC) are loaded.
2.4.1 Creation procedure of equal segment action program
1) Select "1 EQL SEG" from the edit mode menu.
※
※※
※ Follow the mode selection procedure to select.
2) Next, a list of programs stored in the ABSODEX driver is displayed.
Press
to view all numbers.
"←" next to a number indicates the last number.
After checking, press
.
※
※※
※ If the number of displayed program number
characters exceeds 400, the following message
is displayed.
While numbers are displayed as in the regular
case, numbers later than 400 characters are not
displayed.
3) Enter the desired program number to be created,
in the range from 0 to 999, and press
.
4) Select the pre-start home position and press
.
※
※※
※ "-" next to the number indicates the currently
selected option.
(The rule is similar to later steps 10) and 11).)
★
If the number of displayed characters
exceeds 400.
ＩＮＣＯＭＥ ＢＵＦＦ ＯＶ
１ＥＱＬ ＳＥＧ ２ＮＣ →
ＥＤＩＴ ＭＯＤＥ
１ＥＱＬ ＳＥＧ ２ＮＣ →
ＳＴＯＲＥＤ ＰＲＧＭ
１ ２ ９９１ ９９２←
ＥＱＬ ＳＥＧ： ＮＥＷ
ＰＲＧＭ ＮＯ． ［ ］
ＥＱＬ ＳＥＧ：ＨＭＲ ＰＯＳＩ
１－ＨＭＥ ２ ＩＮＤＸ
