[SMB-66E]
－ 25 －
OPERATION
2
2.6 Parameter Mode
The ABSODEX driver has two memory types (RAM and FLASH MEMORY) and parameter data is
stored in each of them.In the parameter mode, you can change the parameter data.Each function is
described below.
1: READ ······················· All parameters are loaded from FLASH MEMORY to Teaching Pendant
and refreshed.
2: CNT ·························· Parameters stored in Teaching Pendant are modified continuously.
3: STORE ····················· Parameters are stored from Teaching Pendant to both FLASH MEMORY
and RAM.
4: INITIA ······················· Parameters stored in FLASH MEMORY and RAM are initialized.
5: RAM ························· The designated parameter data in RAM is changed.
6：CCLink/PROFI/DvNet ··· Serial communication settings, including the station number,
are configured for TS/TH-type drivers.
※
※※
※1. For the description of each parameter, refer to Section 4.1 "Parameters and Contents."
※
※※
※2. New parameters may be added to the main body of the driver for improvement of the function of
ABSODEX. Refer to "ABSODEX Instruction Manual," too.
Enter or modify new parameters at the Terminal in the motion mode.
(Refer to Section 2.7.13 "Terminal operation procedure.")
※
※※
※3. Even if RAM data is changed, the RAM data and parameters in the driver are overwritten by the
FLASH MEMORY parameters if the FLASH MEMORY is changed and the power is turned on again.
2.6.1 Parameter data changing procedure
To change parameter data, follow one of the two methods below.
a) Execute "1 READ" to load parameters from the
ABSODEX driver.
b) Execute "2 CNT" and change the parameter
stored in Teaching Pendant.
After being selected, the selected parameter is
displayed.
※
※※
※ If the Teaching Pendant keeps no parameter data,
the following message is displayed.
In case of continuation, load data from the
ABSODEX driver first to store parameters in
Teaching Pendant.
※
※※
※ If the teaching pendant which contains parameters
for one type of driver is connected to another type
driver and “2CNT” is executed, the message on
the right is displayed. For the parameters indicated,
data loaded from the connected driver is displayed.
※
※※
※ If "2 CNT" is selected and parameters are edited, unchanged parameters having been kept in
Teaching Pendant overwrite those in the driver. Take care of the fact.
Even if a parameter is changed, the parameter data stored in FLASH MEMORY
and RAM of the ABSODEX driver remains unchanged until "3 STORE" in the
menu is executed. (However, this is not the case for initial values and RAM data.)
ＰＡＲＡ
１ＲＥＡＤ ２ＣＮＴ →
Parameter number
Parameter Setting
name
ＣＡＭ ＣＵＲＶ Ｐ０１
［１］ＭＳ
ＮＯ ＣＮＴ ＤＡＴＡ
１ＲＥＡＤ ２ＣＮＴ →
ＮＯ．５，４２～５７，７２
ＲＥＡＤ ＦＲＯＭ ＡＸ
