CKD AX0180 User Manual

[SMB-66E]
－ 29 －
OPERATION
2
2.6.2 Parameter data storage procedure
1) Select "3 STORE" from the parameter menu and
press
.
2) A message is displayed to indicate that the
parameters kept in Teaching Pendant is stored in
both the FLASH MEMORY and RAM.
※
※※
※ Control power must be restarted to make all
parameter settings effective. Press
after
confirming the following message.
3) After the data is stored, the mode selection menu
is displayed again.
※
※※
※ If no parameter is kept in Teaching Pendant, the
following message is displayed.
Load parameters from the ABSODEX driver to
Teaching Pendant first before storing
parameters.
※
※※
※ If the teaching pendant which contains
parameters for one type of driver is connected
to another type driver and “2CNT” is executed,
the message on the right is displayed.For the
parameters indicated, data loaded from the
connected driver is displayed.
※
※※
※ If an alarm is caused while data is stored,
two messages are displayed alternately.
After checking, press
.
The alarm is removed and the parameter menu
screen is displayed again.
Enter the displayed parameter number again.
ＮＯ ＤＡＴＡ ＴＯ ＳＴＯＲＥ
←２ＣＮＴ ３ＳＴＯＲＥ→
Parameter number causing the alarm
へ
Displayed alternately
ＳＴＯＲＥ ＥＲＲＯＲ
ＰＡＲＡ ××
ＰＲＥＳＳ ＲＴＮ ＫＥＹ
ＰＡＲＡ
←２ＣＮＴ ３ＳＴＯＲＥ→
ＰＲＭ
←２ＣＮＴ ３ＳＴＯＲＥ→
＊ＳＴＯＲＥＤ＊
ＴＵＲＮ ＤＲＩＶＥＲ ＯＦＦ
ＴＵＥＮ ＯＮ ＡＧＡＩＮ
ＭＯＤＥ
←２ＤＩＳＰＬＹ ３ＰＡＲＡ→
ＮＯ ＣＨＡＮＧＥＳ ＴＯ
ＮＯ．５，４２～５７，７２
