OPERATION
2
2.7.13.3 Parameter entry method in terminal mode
In the terminal mode, ABSODEX parameters can be modified directly.
[Code to be used and data format]
L7 _ [parameter number] _ [data]
a) As an example, the method for changing the
cam curve (parameter number 1) into a
deformed trapezoid (curve number 3) is
described.
b) For the description of the parameter, use the
following code.
L9 _ [parameter number]
★
To change the cam curve (parameter
number 1) into deformed trapezoid
(curve number 3)
Received data
…
"0" indicates a correct value.
ＴＥＲＭ
＞Ｌ７ １ ３
Ｌ７ １ ３
＞０←
★
To check the description of the
parameter
Parameter description
ＴＥＲＭ
＞Ｌ９ １
Ｌ９ １
＞３←
