ＥＤＩＴ ＭＯＤＥ
←２ＮＣ ３ＲＥＡＤ →
★
If AUTO (EQL SEG) is selected
★
If AUTO (NC) and NC are selected
ＲＥＡＤ
ＰＲＧＭ ＮＯ． ［ ］
ＮＯ ＰＲＧＭ ＮＯ．
ＰＲＧＭ ＮＯ． ［ ９］
ＩＮＣＯＭＥ ＢＵＦＦ ＯＶ
ＰＲＧＭ ＮＯ． ［ ３］
★
If program number 9 is not found
★
If program 3 contains more than 2000
characters
ＲＥＡＤ
ＰＲＧＭ ＮＯ． ［ ］
ＮＯ ＰＲＧＭ ＮＯ．
ＰＲＧＭ ＮＯ． ［ ９］
ＩＮＣＯＭＥ ＢＵＦＦ ＯＶ
ＰＲＧＭ ＮＯ． ［ ３］
2.4.3 Procedure for loading programs from ABSODEX driver
1) Select "3 READ" from the edit mode menu.
※
※※
※ For the selection method, follow the mode
selection procedure.
2) A list of program numbers stored in the ABSODEX
driver is displayed.
Press
to view all numbers.
"←" at the end of the number indicates the last number.
After checking, press
.
3) Enter the program number to be created, and
press
.
※
※※
※ If a program number not found in the driver is
entered, the following error message is
displayed.
※
※※
※ If the number of characters of the loaded
program exceeds 2000, the following message
is displayed.
The program is displayed as in regular cases,
while you cannot edit the 2000th and later
characters in the program.
4) Select the display type on the next screen.
a) Selecting "1 AUTO"
If the entered number is an equal segment
program, the program is displayed in the
interactive format of Teaching Pendant.
If the program is created with NC codes, NC
codes are displayed.
b) Selecting "2 NC"
The program is displayed in NC codes.
※
※※
※ Edit the program in the later steps according to the corresponding program creation procedure
(Section 2.4.1 "Creation procedure of equal segment action program" and "Section 2.4.2 "NC
program creation procedure").
ＳＴＯＲＥＤ ＰＲＧＭ
１ ２ ３ ９９２←
