[SMB-66E]
－ 45 －
2.8 Copy Mode
In the copy mode, one of the following is copied from the ABSODEX driver to another driver.
1: All programs
2: All parameters
3: Both all programs and all parameters
In the copying process, the designated data (above 1 to 3) is loaded from the ABSODEX driver to
Teaching Pendant.
Connect Teaching Pendant to the destination driver and execute the storage process.
The "READ" and "STORE" procedures are described.
2.8.1 Procedure for loading from ABSODEX driver to Teaching Pendant
1) After the copy mode is selected, the following
screen is displayed.
Select "1 READ" and press
.
2) Next, select the data type to be loaded, and press
.
3) After data is loaded, a message is displayed and
the data is stored in Teaching Pendant.
4) The mode selection menu is displayed again.
ＣＯＰＹ ＭＯＤＥ
１ＲＥＡＤ ２ＳＴＯＲＥ
ＣＯＰＹ ＣＯＮＴＥＮＴ
１ＰＲＧＭ ２ＰＡＲＡ →
ＣＯＰＹ ＣＯＮＴＥＮＴ
←２ＰＡＲＡ ３ＢＯＴＨ
＊ＲＥＡＤ ＣＭＰＬＴ＊
１ＰＲＧＭ ２ＰＡＲＡ →
ＭＯＤＥ ＳＥＬＥＣＴ
←４ＭＯＴＩＯＮ ５ＣＯＰＹ
To Next Page
