Clevo X170SM-G User Manual

Power Management
3 - 26 Inserting the Battery
3
Inserting the Battery
1. Orientate the battery as illustrated below and align the battery with the edges of
the battery compartment.
2. Insert it into the compartment in the direction of the arrow (it should click into
place).
3. Slide the latch in the direction of the arrow into the lock position.
Figure 3 - 18
Battery Insertion
1
2
1
2
