Duplo DBM-600T User Manual

1-9
Chapter 1 Before Operation
No. Name Function
[1] Folding back guide unit Unit for aligning the leading and trailing edges of paper conveyed to
the folding section.
(p.5-7)
[2] Folding back guide Aligns the leading and trailing edges of paper conveyed to the folding
section.
(p.2-23) (p.2-25)
[3] Folding side guide Aligns the sides of the paper conveyed to the folding section.
(p.2-14)(p.2-23)
[4] Press roller Presses paper folded into two.
[5] Folding roller Folds paper into two.
(p.2-38)
[6] Fold paper holder Prevents paper conveyed to the folding section from rising.
(p.2-40)
[7] Folding stopper Stops booklets conveyed to the folding section.
(p.2-16)
[8] Fold paper holder height adjustment Adjusts the height of the fold paper holder.
(p.2-40)
[9] LED inner lamp LED lamp for partially lighting up inside the machine.
[10] Press roller gap adjustment lever Adjust the clearance (gap) between the press rollers. Use this when the
surface of a booklet is stripped.
(p.2-36)
[11]
Pressure adjustment lever Adjusts the pressure of the press roller.
(p.2-39)
[12]
Ejection pressure adjustment lever Adjusts the ejection pressure.
(p.2-40)
[13]
Press roller gap xing lever Secure the clearance (gap) between the press rollers.
(p.2-36)
[14]
Fold ejection roller gap knob screw Secures the fold ejection roller gap adjustment lever.
(p.2-36)
[15]
Fold ejection roller gap adjustment
lever
Adjust the clearance (gap) between the fold ejection rollers. Use this
when the surface of a booklet is stripped.
(p.2-36)
[16]
Fold paper holder knob screw Secures the height of the fold paper holder.
(p.2-40)
[17]
Ejection at belt Ejects paper folded into two.
[18]
Page insertion roller height
adjustment
Adjusts the height of the insertion rollers.
(p.2-16)(p.2-39)
[19]
Page insertion roller knob screw Secures the height of the insertion rollers.
(p.2-16)
