EDAN iM3 User Manual

Vital Signs Monitor User Manual Warning-Score System
- 102 -
15.3 Warning-Score Criteria
In EWS interface, select Criteria to check score criteria as following:
Value
3 2 1 0 1 2 3
HR (bpm) ≤40 41~50 51~100 101~110 111~129 ≥130
SYS (mmhg) ≤70 71~80 81~100 101~199 ≥200
RESP (rpm) ≤8 9~20 21~24 25~29 ≥30
TEMP (℃)
≤35 35.1~36.0 36.1~37.9 38~38.9 ≥39
SpO
2
(%)
＜86
86~91 92~93 ≥94
Consciousness NC A V P U
In NEWS interface, select Criteria to check score criteria as following:
Value
3 2 1 0 1 2 3
RESP (rpm) ≤8 9~11 12~20 21~24 ≥25
SpO
2
(%) ≤91 92~93 94~95 ≥96
TEMP (℃)
≤35.0 35.1~36.0 36.1~38.0 38.1~39.0 ≥39.1
SYS (mmHg) ≤90 91~100 101~110 111~219 ≥220
HR (bpm) ≤40 41~50 51~90 91~110 111~130 ≥131
Consciousness A V/P/U
Oxygen Yes No
In MEWS interface, select Criteria to check score criteria as following:
Value
3 2 1 0 1 2 3
HR (bpm) ≤40 41~50 51~100 101~110 111~129 ≥130
SYS (mmhg) ≤70 71~80 81~100 101~199 ≥200
RESP (rpm) <9 9~14 15~20 21~29 ≥30
TEMP (°C)
<35.0 35.0~38.4 ≥38.5
Consciousness A V P U
Age <50 50~70 >70
