A.8 Wi-Fi
IEEE 802.11a/b/g/n
Frequency Band 2.4 GHz & 5 GHz ISM band
Modulation OFDM with BPSK, QPSK, 16-QAM, and 64-QAM
802.11b with CCK and DSSS
Max. Transmit Power
(±2 dBm)
2.4 GHz
17 dBm for 802.11b DSSS
17 dBm for 802.11b CCK
17 dBm for 802.11g OFDM
16 dBm for 802.11n OFDM
5 GHz (not available in USA and in Canada)
10 dBm for 802.11a OFDM
9 dBm for 802.11n OFDM
I/U Ratio (co-channel) ≤20 dB
I/U Ratio (adjacent channel) ≤1 dB
Throughput ≥0.01 Mbps
Latency ≤1 s
Jitter ≤1 s
PER ≤10%
A.9 e-link
Transmit Frequency
2402 MHz ~ 2480 MHz
Frequency Band
2402 MHz ~ 2480 MHz
Modulation
FHSS, GFSK, DPSK, DQPSK
Transmit Power
≥ 0 dBm
I/U Ratio ≤1 dB
Throughput ≥0.01 Mbs
Latency (one way delay) ≤1 s
Jitter (latency variation) ≤1 s
PER ≤10%
