Attaching the Roll Core
What You’ll Need
❏ Take-up roll core that is the same width as the
media
❏ Commercially available adhesive tape
Loading
A
Set the Auto switch to Off.
B
Confirm that the edge of the media is touching
the media holder.
If not, follow the procedure below to have the
edge of the media touch the media holder.
Normal feeding procedure
Hold down the near side of the media feed switch
until the edge of the media reaches the media
holder.
c
Important:
Always press the media feed switch to feed the
media. If the media is pulled by hand, the
media may twist during take-up.
Take-up feeding procedure
Follow the Steps 16 to 18 of "Loading media" to
pull out the media until its edge reaches the
media holder.
U “Loading media” on page 67
C
Loosen the media holder fixing screws on both
sides and adjust the media holders so that the
distance between the two is wider than the media.
If the roll supports are not positioned evenly,
move them so that they are even.
c
Important:
If the left-side media holder handle's shaft is
not visible, rotate the handle as shown in the
illustration until it stops. The roll core cannot
be properly loaded if the handle's shaft is not
visible.
SC-F10000 Series User's Guide
Basic Operations
75
To Next Page
