Printable area
Left and Right Edge Positions of Media
The left and right edges of media recognized by the printer vary, as shown below, according to the Width Detection
settings.
Width Detection On
: The printer automatically detects the left and right edges of the loaded media.
When media edge plates are attached, the edge of the media is recognized as within 7 mm
of the left and right edges of the media.
The edges of the media are not detected correctly if the media edge plates are not
attached correctly.
U “Loading media” on page 67
Width Detection Off
: The center of the black rectangle label in front of the platen (shown in the illustration
below) is recognized as the standard position for the right edge of the media. From the
standard position for the right edge of the media, a position set by a value (300 to 1950)
with Width Detection being set to Off is recognized as the left edge of the media.
SC-F10000 Series User's Guide
Basic Operations
95
