Feasa ICT Series User Manual

FEASA LED ANALYSER
ICT VERSION
Capture Sequence Mode
Set/Put SequenceMode# - Set sequence mode for Fibers
Transmit Receive
setsequencemode#
putsequencemode#
OK
OK
Where:
# represents the sequence mode and is a number in the range 0 – 1.
Description
This command is used to set the number of fibers that will be used in the capture sequence
command. PutSequencemode0 will set all Fiber Channels for the Capture Sequence.
PutSequencemode1 sets a single Fiber Channel for the capture sequence.
If putsequencemode1 is selected the Fiber Channel must be set using the
putSequenceChannel command. Also, when this mode is selected up to 8000 captures can
be stored in memory.
If putsequencemode0 is selected the number of captures is limited to 400.
putsequencemode commands are stored in RAM memory while setsequencemode
commands are stored in Flash memory.
Example 1:
The PC transmits putsequencemode0 to the LED Analyser to instruct it to do sequence capture
on all Fibers. The LED Analyser will return a string OK to the PC.
putsequencemode0
OK
Example 2:
The PC transmits putsequencemode1 to the LED Analyser followed by putsequencechannel05
to instruct it to do sequence capture on Fiber No. 5. The LED Analyser will return a string OK
to the PC.
putsequencemode1
OK
putsequencechannel05
OK
To determine which sequence mode is set, use the command getsequencemode. It will
return a 1 or a 0.
getsequencemode
0 (All Fibers)
Back to Index
111

Feasa ICT Series Specifications

General

Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Application	LED testing
Channels	1
Communication Interface	USB
Power Source	USB
Measurement Parameters	Dominant Wavelength, CCT, CRI
Accuracy	±2% in flux
