Feasa ICT Series User Manual

FEASA LED ANALYSER
ICT VERSION
Get Data Mode
getABSINT@@ - Get the Absolute Intensity Value of the Led under test.
Transmit Receive
getabsint@@
#.####e±##
Where:
@@ represents the Fiber Number and is a number in the range 01 – 20.
#.####e±## represents the Absolute Intensity reading
Description:
This command will allow the user to interrogate the Led Analyser to return the absolute
Intensity Value for the Led under test at Fiber@@.
This command should only be used in conjunction with the Feasa LED Spectrometer.
Absolute Intensity values must first be measured with the Spectrometer. The LED Analyser
must then be calibrated with these values using the usercal program supplied with the
Analyser.
Example:
Place fiber 01 over the Led to be tested. Using any of the Capture commands, capture the
data for that Led. Type the command getabsint01 and the analyser will respond with with
the intensity reading in the format #.####e±##
getabsint01
2.5000e-02
Back to Index
83

Feasa ICT Series Specifications

General

Operating Temperature	0°C to 50°C
Storage Temperature	-20°C to 70°C
Application	LED testing
Channels	1
Communication Interface	USB
Power Source	USB
Measurement Parameters	Dominant Wavelength, CCT, CRI
Accuracy	±2% in flux
