Feasa ICT Series User Manual

FEASA LED ANALYSER
ICT VERSION
Capture Sequence Mode
GetMax(Min)Intensity## - Returns the Max or Min Intensity for the Seq Cap.
Transmit Receive
getmaxintensity##
getminintensity##
iiiii
iiiii
Where:
## represents the Fiber Number and is a value in the range 01 – 20.
iiiii represents the intensity value of the LED under fiber ##. This 5-digit number is
in the range 0000 – 99999. 0000 represents no Intensity or under range(i.e.
the LED is off) and 99999 will represent over range or the LED is too bright.
Description
This command reports the Maximum or Minimum Intensity of the Led under test after the
sequence capture is complete.
Example:
The PC transmits getmaxintensity01 or getminintensity01 to the LED Analyser to instruct
it to report the Maximum or Minimum Intensity of fiber No.1
getmaxintensity01
99800
getminintensity01
00200
Back to Index
128
