Feasa ICT Series User Manual

FEASA LED ANALYSER
ICT VERSION
Set Data Mode
setFREQUENCYxxx - Set the Frequency Output Mode of the Analyser
Transmit Receive
SetFrequencyxxx OK
Where:
xxx represents the Frequency Measuring mode of the Analyser at ICT
HSI represents the Hue, Saturation & Intensity mode.
XyI represents the Xchromaticity, yChromaticity & Intensity mode.
WSI represents the Dominant Wavelength, Saturation & Intensity mode.
Description
The Analyser shipped from the factory is defaulted to FrequencyOut-HSI (Hue, Saturation and
Intensity) Mode, There are 2 other frequency out modes available – WSI (Dominant
Wavelength, Saturation, Intensity) and xyI (xy chromaticity and Intensity)
These commands are used to set the Analyser ICT Interface in Frequency Output mode of your
choice. It must be issued through the Serial Port. The unit will remain in this mode until
instructed otherwise. The status of the ICT Interface can be determined using the
getICTStatus command.
Example:
The PC transmits setfrequencyhsi to the LED Analyser to instruct it to set Frequency Output
Hue, Saturation & Intensity mode.
The PC transmits setfrequencywsi to the LED Analyser to instruct it to set Frequency Output
Wavelength, Saturation & Intensity mode.
The PC transmits setfrequencyxyi to the LED Analyser to instruct it to set Frequency Output
xChromaticity, yChromaticity & Intensity mode.
Setfrequencyhsi
OK
Setfrequencywsi
OK
Setfrequencyxyi
OK
Back to Index
95
