198
8.9 Page Edge Filler (Automatic paper size detection)
8.9 Page Edge Filler
(Automatic paper size detection)
When the scanner is set to detect paper size automatically, depending on the state of the documents, the
black frame may be generated on the output image.
If this is the case, you can improve the output image by using the “Page Edge Filler (Automatic paper size
detection)” function. This function fills the end portion of the image with white so that it looks clean.
Configure the settings for “Page Edge Filler (Automatic paper size detection)” as follows:
1. Start up the Software Operation Panel.
Refer to “8.1 Scanner Settings” on page 177.
2. Select [Device Setting 2] from left side list in the window, and select
[Paper Edge Filter (Automatic Page Size Detection] from its lower level.
3. Specify the Top, Bottom, Right, and Left widths to fill.
D
T
L
R
T : Top edge = 0 ~ 7.5 mm
D : Bottom edge = 0 ~ 7.5 mm
R : Right edge = 0 ~ 7.5 mm
L : Left edge = 0 ~ 7.5 mm
Filled area
Generated
(can be set in increments of 0.5mm)
To Next Page
