9.3 fi-590PRB (Post-imprinter)
9.3 fi-590PRB (Post-imprinter)
fi-590PRB is installed at the rear side of the Transport path, inside of the scanner. It prints after the scan-
ning. fi-590PRB (Post-imprinter) Specifications are described below.
As for the operations and functions of fi-590PRB (Post-imprinter), refer to the fi-590PRB Operator's
Guide attached to fi-486PRRE.
Item Descriptions
Printing Method Thermal Ink Jet
Printable characters Alphabet letters: A to Z, a to z
Numeric characters: 0,1 to 9
Symbols: ! ” # $ % & ’ ( ) * + , - . / : ; < = > ? @ [ \ ] ^ _ ` { | } ¯
Maximum printable char-
acters per line
43 characters
Print Orientation Normal: 0º, 180º (horizontal), 90º, 270º (vertical)
Narrow: 0º, 180º (horizontal)
Character size Normal: Height 2.91mm x width 3.03mm / 0.1146 x 0.1193 in (horizontal)
Height 3.03mm x width 2.91mm / 0.1193 x 0.1146 in (vertical)
Narrow: Height 2.91mm x width 1.71mm / 0.1146 x 0.0673 in (horizontal)
Character pitch 3.79mm / 0.1492in (Normal), 2.46mm /0.0968in (Narrow)
Font Style Regular, Bold
Character Width Normal, Narrow
Printing area
Printing Position
Accuracy
Vertical: ±4mm
Horizontal: ±4mm
Consumables Print Cartridge
Feeding direction
Head movable range
Reference
Point
Post-printing area (back side)
* The document stains with ink when
printing in the shaded areas (shown
in the illustration). Therefore,
correct printing operations in such
areas are not guaranteed.
Unit: mm
