Concluding steps
▶
Insert all HDD/SSD modules, see "Installing a 2.5-inch HDD/SSD module"
on page 140
.
Make sure that you reinstall the HDD/SSD module in the bay it was
located before the HDD backplane replacement.
▶
Insert all dummy modules, see "Installing a 2.5-inch dummy module" on
page 143.
▶
"Reassembling" on page 53
.
▶
"Connecting the power cord" on page 57.
▶
"Switching on the server" on page 60.
▶
If applicable, "Installing the front cover with lock" on page 61.
7.5.6 Replacing the right side 4x 2.5-inch HDD
backplane
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
The 4x 2.5-inch HDD backplane is available in a SAS/SATA or NVMe
variant depending on the configuration.
Preliminary steps
▶
"Locating the defective server" on page 43.
▶
If applicable, "Removing the front cover with lock" on page 45.
▶
"Shutting down the server" on page 46.
▶
"Disconnecting the power cord" on page 47.
▶
"Getting access to the component" on page 49.
Hard disk drive (HDD) / solid state disk (SSD)
RX1330 M5 Upgrade and Maintenance Manual 149
