16.1.2 Server rear
16.1.2.1 Server rear with standard PSU
Figure 266: Server rear with standard PSU
1 Standard PSU
2 PCIe slot 3 / riser module 3
3
PCIe slot 2 / riser module 2
4 PCIe slot 1 / riser module 1
5 I/O panel
Figure 267: Server rear with full height riser module
1 Full height riser module
As an option, a full height riser module can be installed. In this case the
slot 2 is not available and slot 3 can be equipped with a full height
expansion card.
