GE Baker Hughes PanaFlow LC XMT1000 User Manual

Appendix A. Specifications and Model Configurations
96 PanaFlow™ LC User’s Manual
A.3 Part Number Information
A — B C D - E F G H - I - PREPRO - REPOR PMI Z
bW^:888LC
A - MODEL:
bW^:888 VM TRANSMITTER
B - PATHS:
1
Single path with w/ MCX Connectors
2
Two or three path with w/ MCX Connectors
3
Single path with Flying Leads
4
Two path with Flying Leads
C - POWER:
AC
100-240 VAC power supply
DC
12-28 VDC power supply
D - CONFORMAL COATING:
0
No Conformal coating
1
With Conformal coating
E: ENCLOSURE:
AL
Powder coated AL enclosure
SS
316 st Current inputnless steel enclosure
F - INPUT/OUTPUT:
00
No additional input/output
01
2 Current Outputs, 2 Current inputs
02
2 Current Outputs,1 Current input,1 RTD input-PT100,
3 Wire
03 2 Current Outputs,2 RTD inputs-PT100, 3 Wire
04 2 Current Outputs,1 Current input,1 RTD input-PT100, 4 Wire
05 2 Current Outputs,2 RTD inputs-PT100, 4 Wire
06 2 Current Outputs,1 Current input,1 RTD input-PT1000, 3 Wire
07 2 Current Outputs,2 RTD inputs-PT1000, 3 Wire
08 2 Current Outputs,1 Current input,1 RTD input-PT1000, 4 Wire
09 2 Current Outputs,2 RTD inputs-PT1000, 4 Wire
G - CERTIFICATIONS:
1
US/CAN Cl 1, Div 1, Grp BCD T6
2
IECEx/ATEX Exd IIC T6 Gb IP66
H - DIGITAL COMMUNICATIONS:
0
No additional comm.
1
HART with 4 dynamic variables
2
Foundation Fieldbus
I - FREQUENCY:
0
Standard Frequency
PREPRO - PREPROGRAMING:
PREPRO
Preprogramming
REPOR - TEST REPORT:
RPT
Test Report

Z - SPECIAL:
0
None
S
SPECIAL Consult Factory
bW^:888LC-2 -AC -01 -SS -01 -1
-0 -0 -PREPRO -RPT
-S
(EXAMPLE PART NUMBER STRING)

GE Baker Hughes PanaFlow LC XMT1000 Specifications

General

Brand	GE
Model	Baker Hughes PanaFlow LC XMT1000
Category	Measuring Instruments
Language	English
