PanaFlow™ LC User’s Manual 149
Appendix H. Foundation Fieldbus Communication
H.5 XMIT Transducer Block
The XMIT transducer block contains parameters that can be transmitted onto the Fieldbus via the AI block.
The user can view real time data and select the units for each of the parameters (see Figure 134 below).
Figure 134: Measurement Parameters and Units in XMIT Transducer Block
Invalid Parameter Range
Warning
Invalid Parameter Range - Warning Check
Invalid Request Warning Invalid request - Warning Check
Invalid User Warning Invalid User - Warning Check
Table 36: NAMUR NE107 Errors and XMT1000 Default Categories
Error Sub-Error Description Default Category
