Chapter 4. Error Codes and Troubleshooting
82 PanaFlow™ LC User’s Manual
RCV: Receive signal allows the user to look at the receive signal before it is processed by the meter. It is
usually looked at along with the TWIND and RWIND. Use ARTN with RCV signal.
4.7 System Errors (S-Errors)
These errors are from the Flow subsystem. The system errors have 4 types of information.
1. Indicator
2. Warning
3. Error
4. Fault
The indicator is just a notification to the operator, no action is needed. The warnings are usually indicative of
an operator error. Errors indicate failures that need attention. Operator should perform recommended
actions to recover from these errors. Faults are usually indicative of more serious failures related to
background hardware / software integrity checks performed by XMT1000 meter. See the table below for error
codes, error messages, error type and recommended actions.
Table 23: Gate connections
TWIND: Transmit Window
use DRTN with TWIND
RWIND: Receive Window use DRTN with RWIND
Table 24: System Error Description and Recommended Actions
Error Code Error Message Description / Recommended Action
S1: In Config Mode In configuration mode
indicator
Indicator: This is displayed when a user has
logged in to either Operator, Admin or Factory
access level. The indicator will clear
automatically when the user logs out or saves
the configuration changes
S2: Invalid User Invalid user warning Warning: The passcode entered for access level
is incorrect. Please log in with the correct access
level and passcode
S3: Invalid Request Invalid request warning Warning: An invalid communication packet was
received and discarded. Or, the requested
operation is invalid. Please send a valid packet
or operation request
S4: Invalid Param
Range
Invalid parameter range
warning
Warning: The value programmed for the
parameter was out of range and hence
discarded. Please enter a valid range
S5: Unsupported
Parameter
This parameter is not
supported
Warning: A read or write request to an
unsupported parameter was received
