Plant reference (user-defined)
For example:
Plant Reference
MiCOM
HOTKEY
Access Level
For example:
Access Level
3
HOTKEY
In addition to the above, there are also displays for the system voltages, currents, power and frequency etc.,
depending on the device model.
3.4 DEFAULT DISPLAY NAVIGATION
The following diagram is an example of the default display navigation. In this example, we have used a cyber-
secure model. This is an example only and may not apply in its entir
ety to all models. The actual display options
available depend on the exact model.
Use the horizontal cursor keys to step through from one display to the next.
NERC compliant
ba
nner
V00403
Access Level
System Current
M
e
asurements
System Frequency
System Voltage
Me
asurements
System Power
Me
asurements
Date & Time
Plant Reference
Description
NERC Compliance
Wa
rning
NERC Compliance
Wa
rning
Figure 28: Default display navigation
Chapter 5 - Configuration P14x
74 P14xEd1-TM-EN-1
