7.2.2 SENSITIVE OVERVOLTAGE FILTER MODE LOGIC

V00813

0.80*Freq

0.90*Freq

0.95*Freq

1.00*Freq

1.05*Freq

1.10*Freq

1.20*Freq

SOV Filter Mod

Enabled

Disabled

Setting factor

Apply setting

factor

Set factor to 1

Enable

Disable

Setting factor

SOV>Curve Err

Figure 124: Sensitive Overvoltage filter mode logic

7.2.3 SENSITIVE OVERVOLTAGE BLOCKING LOGIC

V00814

Freq Not Found

SOV>Curve Err

Frequency buffers full

SOV1 blocked

SOV Frequency Out of Range

SOV>1 Timer Blk

Stop Freq Track

Figure 125: Sensitive Overvoltage blocking logic
